Product description
RoboMaster Referee System Video Transmission Module (including the transmitter and the receiver, hereinafter referred to as the "VTM") is an image capture and wireless transmission system featuring high resolution, high frame rate, and low latency. Multiple VTMs can work simultaneously. The RoboMaster Video Transmission Module receiver does not require installation and can be connected to a computer, featuring data transmission and image output capabilities. When used in conjunction with the RoboMaster Competition Engine Player Side, it can provide display functionality. Additionally, the receiver can serve as a remote controller to send control data, corresponding one-to-one with the transmitter for remote data transmission. As a component of the RoboMaster University Series Referee System (hereinafter referred to as the "Referee System"), the VTM provides a first-person view of robots. The VTM cannot be used independently.
Product Specifications
Operating Temperature: -10° to 40° C (14° to 104° F)
Operating Frequency (China and other non-Japan regions): 5150-5250 MHz (indoor use only), 5732-5829 MHz
Operating Frequency (Japan): 5150-5250 MHz, 5650-5755 MHz
Video Resolution Maximum: 1920×1200
Video Frame Rate Maximum: 60 Hz
End-to-End Latency: < 90 ms (laboratory environment)
Max Transmission Range: 100 m (without any obstruction)
Weight Approx.: 375 g
Max Operating Time: 6 hours
Charging Temperature: 5° to 40° C (41° to 104° F)
Related download
- download
DJI Assistant 2(RoboMaster Series) 2.0.0.12.2769
Updated on: 2025-06-23
- download
Example_Code_for_Data_Frame_and_Validation.c
Updated on: 2025-06-23
- download
RoboMaster Referee System Video Transmission Module VT03&VT13 User Guide
Updated on: 2025-06-23
- download
USB_Driver_Installer_32bit&64bit_5.0.7
Updated on: 2025-06-23
